China Manufacturer Semi-automatic Brazing Welding Frame Rack Machine for circular diamond saw blade BWM-HJ350China Manufacturer Semi-automatic Brazing Welding Frame Rack Machine for circular diamond saw blade BWM-HJ350China Manufacturer Semi-automatic Brazing Welding Frame Rack Machine for circular diamond saw blade BWM-HJ350China Manufacturer Semi-automatic Brazing Welding Frame Rack Machine for circular diamond saw blade BWM-HJ350China Manufacturer Semi-automatic Brazing Welding Frame Rack Machine for circular diamond saw blade BWM-HJ350

China Manufacturer Semi-automatic Brazing Welding Frame Rack Machine for circular diamond saw blade BWM-HJ350

  • Model: BWM-HJ350
  • Voltage: 220V/50HZ
  • Current: 60A
  • Rated Capacity: 370W
  • Rated Duty Cycle: 100%
  • Welding Range: 350mm - 2500mm(Max 3500m
  • Verticality: 0.3mm; 0.3mm
  • Water Consumption: 1.5 - 2m³/h
  • Welding Rate: 4-20 PCS/Min
  • Welding Type: High-frequency induction brazing welding
Introduction:

Brief Introduction:

The "BWM-HJ350" Semi-Automatic Brazing Welding Frame Rack Machine is used for Welding Diamond Circular Saw Blade fromø400mm to ø3500mm ( Should be boosted 1700mm high). In addition, it also can be used for welding gang saw blade after specially modification, It is a new type of diamond saw blade welding auxiliary equipment.

This machine has gripper, pneumatic sliding table and other high-precision components, thus greatly improving the welding accuracy and efficiency, to protect the segments and the base of the welding strength. Compared with similar welding machine with a high level of automation, positioning accuracy, stability, and long service life.This series of products using user-friendly design, general workers can operate on the machine.In addition, the welding machine compact structure, most of the wearing parts can be found and purchased in the pneumatic tools shop in your side, rather than relying on the service agents.



Features:
1. Welding diameter range can be adjusted ;
2. Welding frame structure is compact and reliable ;
3. High efficiency and accuracy,low energy consumption ;
4. High level of automation, good stability, long service life ;
5. Most of the wearing parts are available in all parts of the hardware store to buy your own replacement, convenient and quick.

All of our products have been strictly tested before access to market.
Other specifications can be customized according to requirements.
Details:                                                                
 Specification of semi-automatic diamond circular saw blade welding machine:

Model No.:  BWM-HJ350

Welding Range

MM

Ø400 – Ø3500(Normal Max Ø1800)

Verticality

MM

≤±0.03

Parallelism

MM

≤±0.03

Welding Rate(Segments Qty/Min)

PCS/Min

6 – 12

Air Pressure

Mpa

0.3 - 0.6

Water Pressure

Mpa

≥0.2

Voltage

V

220 (Single-phase), 50HZ

Power

W

550

Water Consumption

M³/h

1.5 - 2.0

Machine Dimensions

MM

L900 * W700 * H2400 (Stand)

Machine Weight

KG

330

Package Dimensions

MM

L2530 * W960 * H780 (Horizontally)

Package Weight(Wooden Packing)

KG

380

Note :This machine doesnt include high frequency welding machine , air compressor and water pump.


Pictures:
The following shows are only part of diamond saw blade welding rack,if you want to know more details,please contact us.
 Welding Machine Rack Front:          Welding Machine Rack Behind:
Semi-automatic welding frame rack for diamond saw bladeSemi-Automatic Welding Frame Machine for circle diamond saw blade
Welding Machine Rack Detail :
Semi-Automatic Welding Frame Machine for circle diamond saw bladewelding rack machine details
Semi-Automatic Welding Frame Machine for circle diamond saw bladewelding rack machine details
BWM-HJ350 Welding Machine Tool Box
welding machine tool box
The Packing of Welding Frame Rack For Circle Diamond Saw Blade:
welding frame machine packingwelding frame machine packing
Packing

Diamond saw blade welding frame rack packing in the wooden.
We can also pack the saw blade welding rack according to your requirements.
Special specifications need to be negotiated for delivery times.
