60 ton intelligent hydraulic pressed machine
- Model Number: BWM-HP-60
- Total power: 7.5 KW
- Voltage: 380 V
- Pressure: 0 - 60 Ton
- Oil tank volume: 230L
- Volume of machine:760mm * 1600mm * 2300mm ( L*W*H )
- Applications: The BW-HP60 intelligent hydraulic pressed machine is designed for processing the press pieces of diamond segments. The control system uses new industrial PLC man-machine interface technology,reliable,intuitive and easy to understand,It’s max pressure can up to 60 ton.
- Industry: Boreway machine
- Advantage: High quality and Long lifespan.
Introduction:
The BW-HP60 intelligent hydraulic pressed machine is designed for processing the press pieces of diamond segments. The control system uses new industrial PLC man-machine interface technology,reliable,intuitive and easy to understand.It’s max pressure can up to 60 ton.
Features:
1. High precision ,reliable performance ,stable compressure and never stucking mould .
2. The machine specializes in producing gang saw segments,diamond segments and abnormal shape segments.
3. It uses positive displacement and designs automatic feeding.
4. The operation system uses touch screen, very intuitive and understandable.
5. Easily operation , it is easily for a person to operate 3-10 sets of this kind machines .
6. Each time it can suppress 1-6 pieces( following with mould changes) , improving the production efficiency.
7. Its working pressure is controled by pressure switch.
Specifications:
The followings are the normal specifications of our 100 ton intelligent hydraulic pressed machine:
|
Parameters |
Numerical |
|
Type |
BW-HP60 |
|
Total power |
7.5 KW |
|
Voltage |
380 V |
|
Working current |
18 A |
|
Control system voltage |
24 V |
|
Pressure control range |
0 - 60 Ton |
|
Oil tank volume |
230 L |
|
Pressure range |
Min weight 0.5g ( Including diamond powder ) |
|
Min weight 0.4g ( Not including diamond powder ) |
|
|
Max weight 50g ( Following with mould ) |
|
|
Control system |
Industry PLC and touch screen |
|
Volume of machine |
760mm * 1600mm * 2300mm ( L*W*H ) |
|
Weight |
1800 Kg |
|
Error range |
±0.02 g/pc |
|
Production quantity |
1200 times/h |
The above specifications are for reference, other or special specifications can be ordered by customers.
