Diamond block cutting segment for sandstone
- Model Number: BW-DBCSS-001
- Type: Wet Use
- Diameter: 900mm to 2700mm
- Steel core: 5mm to 9mm
- Segment number: 64-140
- Segment shape: Z (Straight)
- Applications: Boreway diamond block cutting segment for sandstone is welding on saw blade for cutting sandstone.
- Machine: Large cutting machine.
- Industry: Diamond tools
- Welding method: Sinter welding
- Advantage: Good sharpness and Long lifespan.
Introduction:
These diamond block cutting segments are used for cutting sandstone and other soft crisp stone.
Smooth cutting without edge damage.
Features:
1.The segments have good sharpness and high efficiency at the process of cutting,meanwhile,
it has a long lifespan.
2.Good cutting result: smooth cutting,flat surface and even size.
3.Stable cutting,narrow cutting gap,stone waste reduction.
4.M-shaped segment is easy for diamond opening.
Specifications:
The followings are the normal specifications of our Diamond Block Cutting Segment for Sandstone:
|
Product Name |
Diameter |
Steel Core (mm) |
Segment Dimension (mm) |
Segment Number |
Shape |
Application |
|
Boreway Block Cutting Segment For Sandstone |
Ø900 |
5.0 |
24*7.5*13(15) |
64 |
Z (Straight) |
Sandstone |
|
Ø1000 |
5.0 |
24*7.5*13(15) |
70 |
|||
|
Ø1200 |
5.5 |
24*8.0*13(15) |
80 |
|||
|
Ø1400 |
6.0 |
24*8.5*13(15) |
92 |
|||
|
Ø1600 |
7.0 |
24*9.5*13(15) |
108 |
|||
|
Ø1800 |
7.5 |
24*10*13(15) |
120 |
|||
|
Ø2000 |
8.0 |
24*11*13(15) |
128 |
|||
|
Ø2200 |
8.0 |
24*11*13(15) |
132 |
|||
|
Ø2500 |
9.0 |
24*12.5*13(15) |
140 |
|||
|
Ø2700 |
9.0 |
24*12.5*13(15) |
140 |
The above specifications are for reference, other specifications can be ordered by customers.
