Boreway fan edge cutting blade and segment for granite

  • Model Number: BW-FECBSFG-001
  • Type:          Wet Use
  • Diameter: 300mm to 850mm
  • Steel core: 2.2mm to 4.5mm
  • Applications: Boreway fan edge cutting balde and segment for granite is wet use for cutting granite.
  • Machine: Bridge cutting machine and other large cutting machine.
  • Industry: Diamond cutting tools
  • Welding method: Sinter welding
  • Advantage: Good sharpness and long lifespan.

Introduction:

Diamond Fan edge cutting blade and segments are suitable for slab edge cutting of granite and

other hard stone.Suitable for bridge cutting machines.



Features:

1.Good continuity,effectively reduce the distance between teeth.

2.Further Strengthen the effect of trimming,reduce the loss of stone.

3.This segment will improve the sharpness and cutting efficiency.

4.High cutting efficiency,meanwhile,it has a long lifespan.



Specifications:

The followings are the normal specifications of our fan edge cutting blade and segment for granite:

Product Name

Diameter
(mm)

Steel Core

(mm)

Segment Dimension

(mm)

Segment Number

Application

Edge

Cutting

Blade

For

Granite

Ø300

2.2

43/40*3.2*10(15,20)

21

Granite

Ø350

2.2

43/40*3.2*10(15,20)

24

Ø400

2.6

43/40*3.6*10(15,20)

28

Ø450

3.0

43/40*4.0*10(15,20)

32

Splitting

Blade

For

Granite

Ø500

3.0

40*4.0*10(15,20)

36

Ø550

3.6

40*4.6*10(15,20)

40

Ø600

3.6

40*4.6*10(15,20)

42

Ø650

4.0

40*5.0*10(15,20)

46

Ø700

4.0

40*5.0*10(15,20)

50

Ø750

4.0

40*5.0*10(15,20)

54

Ø800

4.5

40*5.5*10(15,20)

57

Ø850

4.5

40*5.5*10(15,20)

58

The above specifications are for reference, other specifications can be ordered by customers.
