Welding frame for diamond drill bits

Welding frame for diamond drill bits

  • Brand Name:Boreway
  • Model:BWM-GHB20/300B,BWM-GHN20/300C
  • Brazing diameter: 20-300mm
  • Brazing height: 60-500mm
  • Brazing speed:15-20 second per segment
  • Positioning accuracy:Surface of segment tolerance:±0.05mm
  • Blade symmetry tolerance:±0.05mm
  • Advantage:We adopt easy design of halving to fix the position,which enable the worker to use the rack with basic training.
Product Description:
Brief Introduction:
High precision brazing frame for diamond core drill is a newly developed machinery for the industry.It’s easy to operate,precise,stable & high cost to performance ratio, comparing to imported machine.The machine improves the brazing precision & torque strength of diamond drill bits and reduces sharpening & labor cost significantly.All pneumatic system,automatically halve to fix the position by electric control (set halving to 2~30 parts).Type C machine can automatically halve to fix the position,locate cutter head,heat,cool off and reset.
Features:
1* Welding diameter range can be adjusted ;
2* Welding frame structure is compact and reliable ;
3* High level of automation, good stability, long service life ;
4* To ensure the welding diamond segments and the matrix strength ;
5* Automatic high-frequency heating, cooling quickly, the segment clamp tightly ;
6* Most of the wearing parts are available in all parts of the hardware store to buy your own replacement, convenient and quick.
All of our products have been strictly tested before access to market.
Other specifications can be customized according to requirements.

Details:
Specification of welding rack for diamond drill bits
Brazing Diameter: 20-300mm
Brazing Height: 60-500mm
Brazing speed:15-20 second per segment
Positioning accuracy:Surface of segment tolerance:±0.05mm
Blade symmetry tolerance:±0.05mm
Pictures:
The following shows are only part of diamond drill bits welding rack.
If you want to know more details,please contact us.
BWM-GHB20/300B diamond core drill bits welding rack



Note:This machine doesn’t include high frequency Welding machine , air compressor and water pump.
Related Products:
High frequency induction welding machine for welding tools

Packing & Shipping:
Diamond drill bits welding frame packing in the wooden.
We can also pack the drill bits welding rack according to your requirements.
Special specifications need to be negotiated for delivery times.
