Crown segment diamond core drill bit
- Model Number: BW-DS-DB-C06
- Type: Wet Use
- Diameter: 20mm to 50mm / 51mm
- Segment length: 100mm
- Adaptor: 5/8 "-11 or M14 or 1/2" Gas
- Applications: Boreway crown segment diamond core drill bit is wet use for drilling granite, marble, artificial stone and quartz.
- Machine: Hand-held drilling machine and other drilling machine.
- Industry: Diamond drilling tools
- Welding method: Sinter welding
- Advantage: Good sharpness high speed and long lifespan.
Introduction:
Crown segment diamond core drill bits are suitable for electrical hand-held drillers or CNC machines
for drilling small holes on kinds of stone such granite, marble, sandstone, limestone, slate, etc.
Features:
1.Applicable for most stand drilling machines, hand-held drillers or CNC machines.
2.Wet drilling and dry drilling are both ok upon clients' demands.
3.Good balance and stable performance.
4.High efficiency and longer lifespan.
Specifications:
The followings are the normal specifications of our crown segment diamond core drill bit ::
|
Product Name |
Diameter |
Segment Size |
Length |
Adaptor |
Applications |
|
Small Diameter Diamond Core Drill Bit |
20mm (3/4 ") |
¢ 20x3x8 / 10 |
4 '' (100mm) |
5/8 "-11 M14 1/2 Gas |
Granite Marble Artificial Stone Quartz |
|
22mm (7/8 ") |
¢ 22x3x8 / 10 |
||||
|
25mm (1 ") |
¢ 25x3x8 / 10 |
||||
|
29mm (1-1 / 8 ") |
¢ 29x3x8 / 10 |
||||
|
32mm (1-1 / 4 ") |
¢ 32x3x8 / 10 |
||||
|
35mm (1-3 / 8 ") |
¢ 35x3x8 / 10 |
||||
|
38mm (1-1 / 2 ") |
¢ 38x3x8 / 10 |
||||
|
42mm (1-5 / 8 ") |
¢ 42x3x8 / 10 |
||||
|
45mm (1-3 / 4 ") |
¢ 45x3x8 / 10 |
||||
|
48mm (1-7 / 8 ") |
¢ 48x3x8 / 10 |
||||
|
50 / 51mm (2 ") |
¢ 51x3x8 / 10 |
The above specifications are for reference, other specifications can be ordered by customers.
Quality: Normal, Good quality, Premium.
