Diamond drill hole saw,diamond drill bit,coring bit,diamond core bit

Model: BW-DDB-S03
Type: Wet or dry use
Diameter: 26mm
Length: 76mm
Applications: Dry or wet use for granite,marble and many other stone for drilling holes.
Adaptation machines: Stand drilling machines or electrical hand-held drillers or CNC machine
Advantages: Good stable and long lifespan.

Introduction:

Diamond bit hole saw produced by silver or laser welding.It can be suitable for stand drilling machines or

electrical hand-held drillers or CNC machine.For drilling kinds of granite or hand stone. Common uses would

be small projects such as drilling out sink holes for faucets.

And silver welded is better for wet use and laser welded is better for dry use.

Features:

1.Designed for drilling holes.

2.Long lifespan and high efficiency.

3.Dry or wet use.

Specification：

There are normal specification of the diamond bit hole saw:

Code No.	Diameter	Segment Size	Use	Pipe Length	Welding Method	Adaptor
BW-DDB-S03	20mm (3/4”)	17/12x3x10	Wet or Dry	4" (100mm)	Silver Welding or Laser Welding	5/8"-11 M14 1/2 Gas
	22mm (7/8”)	17/12x3x10
	25mm (1”)	17/12x3x10
	29mm (1-1/8")	17/12x3x10
	32mm (1-1/4”)	16x3x10
	35mm (1-3/8”)	16x3x10
	38mm (1-1/2”)	16x3x10
	42mm (1-5/8")	16x3x10
	45mm (1-3/4”)	16x3x10
	50/51mm (2”)	16x3x10
	57mm (2-1/4”)	22x3.5x10
	60mm (2-3/8”)	22x3.5x10
	63mm (2-1/2”)	22x3.5x10
	70mm (2-3/4”)	22x3.5x10
	76mm (3”)	22x3.5x10
	80mm (3-1/8”	22x3.5x10
	89mm (3-1/2”)	22x3.5x10
	102mm (4”)	22x3.5x10
	110mm (4-3/8”)	22x3.5x10
	127mm (5”)	24x4x10

The above specification just a reference for customer.Other specification can be ordered by clients.
