Boreway horizontal cutting blade and segment for marble

  • Model Number: BW-HCBSM-001
  • Type:          Wet Use
  • Diameter: 350mm to 650mm
  • Segment number: 21 to 40
  • Steel core: 3.0mm to 7.5mm
  • Applications: Boreway horizontal cutting blade and segment is wet use for marble.
  • Machine: Hand-held cutting machine or large cutting machine.
  • Industry: Diamond cutting tools
  • Welding method: Sinter welding
  • Advantage: Good sharpness and long lifespan.

Introduction:

These cutting blade and segment are widely used for cutting the slab from the block bottom edge

after vertically cutting,to unload slabs from blocks.



Features:

1.The blade has good sharpness and high efficiency at the process of cutting,meanwhile,it has a

long lifespan.

2.Excellent comprehensive cutting performance.

3.Fast cutting and refine edge cutting quality.



Specifications:

The followings are the normal specifications of our horizontal cutting blade and segment for marble:

Product Name

Diameter
(mm)

Steel Core

(mm)

Segment Dimension

(mm)

Segment Number

Application

Horizontal

Cutting

Segment

And

Blade

For

Marble

Ø350

7.5/3.0

40*4.4*10(15)

21

Marble

Ø400

7.5/3.0

40*4.4*10(15)

24

Ø450

7.5/3.0

40*4.4*10(15)

26

Ø500

7.5/3.0

40*5.0*10(15)

30

Ø550

4.0

40*5.0*10(15)

32

Ø600

4.0

40*5.0*10(15)

36

Ø650

4.5

40*5.0*10(15)

40

The above specifications are for reference, other specifications can be ordered by customers.
