Boreway fan edge cutting blade and segment with U gullet

  • Model Number: BW-FECBSUG-001
  • Type: Wet Use
  • Diameter: 300mm to 850mm
  • Steel core: 2.2mm to 4.5mm
  • Applications: Boreway fan edge cutting balde and segment with U gullet for granite is wet use for cutting granite.
  • Machine: Bridge cutting machine and other large cutting machine.
  • Industry: Diamond cutting tools
  • Welding method: Sinter welding
  • Advantage: Good sharpness and long lifespan.
Introduction:

Diamond edge cutting blade with U gullet design on segment circumference allows extremely

high cutting efficiency.


Besides,this creative design of segment structure reduces blade stone interface while cutting,decreases cutting friction. Meanwhile,it makes ideal debris removal and better cooling,reduces frictional heat gain and noise produced by resonance effectively.


Mainly used for cutting and splitting granite and other hard stone.

Feature:

Fan Edge Cutting Blade And Segment With U Gullet


1.Good continuity,effectively reduce the distance between teeth.


2.Further Strengthen the effect of trimming,reduce the loss of stone.


3.This segment will improve the sharpness and cutting efficiency.


4.Good cutting result.This special design will not allow easy edge collapse,break,tapered slab etc.



Specification:

The followings are the normal specifications of our fan edge cutting blade and segment with U gullet:


Product Name

Diameter
(mm)

Steel Core

(mm)

Segment Dimension

(mm)

Segment Number

Application

Edge

Cutting

Blade

For

Granite

Ø300

2.2

43/40*3.2*10(15,20)

21

Granite

Ø350

2.2

43/40*3.2*10(15,20)

24

Ø400

2.6

43/40*3.6*10(15,20)

28

Ø450

3.0

43/40*4.0*10(15,20)

32

Splitting

Blade

For

Granite

Ø500

3.0

40*4.0*10(15,20)

36

Ø550

3.6

40*4.6*10(15,20)

40

Ø600

3.6

40*4.6*10(15,20)

42

Ø650

4.0

40*5.0*10(15,20)

46

Ø700

4.0

40*5.0*10(15,20)

50

Ø750

4.0

40*5.0*10(15,20)

54

Ø800

4.5

40*5.5*10(15,20)

57

Ø850

4.5

40*5.5*10(15,20)

58

The above specifications are for reference, other specifications can be ordered by customers.
